Aluminum Louvers System – Ventilation with Style and Strength

The Aluminum Louvers System by ADS SYSTEMS is designed for modern architectural applications that demand both aesthetic appeal and functional performance. Constructed using high-grade 6063 aluminum alloy, this louver solution offers strength, weather resistance, and clean sightlines.

Perfect for ventilation, shading, and visual privacy, the system supports glass up to 32mm, with dual operational configurations and a sleek 66mm louver blade profile.

Technical Specifications

• Material: 6063 Aluminum Profile Alloy

• Glass Compatibility: Up to 32mm thick

• Max Shutter Height: 3200mm (with dual operation)

• Max Shutter Width: 1000mm

• Louver Blade Size: 66mm

Ideal Applications

• Residential façades and privacy screens

• Commercial and retail exterior shading

• Industrial ventilation panels

• Hotels, lobbies, and sun control systems

• Modern building envelopes and curtain walls

 Key Features & Benefits
Architectural Functionality
Efficient airflow, sun control, and privacy in a visually pleasing system suitable for both façades and interiors.

High-Performance Material
Manufactured from 6063-grade aluminum, known for excellent corrosion resistance and structural strength.

Large Panel Capability
Accommodates tall shutter heights (up to 3200mm) with two-operation functionality for flexible design solutions.

Sleek Louver Blades
The 66mm blade design ensures optimal air circulation and shading with a modern, minimal profile.

Glass Integration
Compatible with glass up to 32mm thick, allowing both transparent and opaque panel options.
